SATELLITES TRACKING
|
USER INTERACTION
|
|
Channels
|
965
|
Indicators
|
4 LEDs indicating battery/charging,
satellite tracking, correction data
transmission, and static recording
|
|
BDS
|
B1I, B2I, B3I, B1C, B2a, B2b
|
Button
|
2 buttons for power and function
|
|
GPS
|
L1C/A, L1C, L2C, L2P(Y), L5
|
ELECTRICAL
|
|
GLONASS
|
G1, G2, G3
|
Power consumption
|
2.0 W2
|
|
Galileo
|
E1, E5a, E5b, E6
|
Input voltage
|
DC 9~28V
|
|
QZSS
|
L1C/A, L1C, L2C, L5
|
Battery
|
- 6700 mAh, over 20 hours working time
- Fast charge of 3 hours charging time
|
|
NavIC
|
L5
|
PHYSICAL
|
|
SBAS
|
WAAS, EGNOS, SDCM, BDSBAS, GAGAN
|
Size
|
φ133.5mm*67mm
|
|
L-Band
|
Support
|
Weight
|
870 g
|
|
Cold start
|
<30s
|
Storage
|
8 GB
|
|
RTK Initialization Time
|
<5s(typical)
|
Housing material
|
Magnesium-aluminum alloy
|
|
RTK initialization reliability
|
>99.9%
|
Speaker (optional)
|
For voice broadcast of real-time status
|
|
Re-acquisition
|
<1s
|
ENVIRONMENTAL
|
|
Accuracy
|
Working temperature
|
-40℃ to +65℃
|
|
Standalone
|
1.5m Horizontally
2.5m Vertically
|
Storage temperature
|
-55℃ to +85℃
|
|
DGPS
|
0.4m Horizontally
0.8m Vertically
|
Humidity
|
100% non-condensing
|
|
Static post-processing
|
2.5mm+0.5ppm Horizontally
5mm+0.5ppm Vertically
|
Waterproof & dustproof
|
IP68
|
|
RTK
|
8mm+1ppm Horizontally
15mm+1ppm Vertically
|
Drop
|
Designed to survive a 2m drop onto concrete
|
|
PPP
|
5cm Horizontally
10cm Vertically
|
|
|
|
SBAS
|
< 1.0 m 3D RMS
|
1. The enhanced UHF base is not compatible with normal UHFrovers on the market. For different user needs, SunNav alsoprovides normal UHF as an option compatible with UHF of otherbrands. Please clarify your requirements when placing the order.
2. The power consumption varies with the different work modes.
3. Storage can be expanded to 32GB according to user demands.
All specifications are subject to change without notice
|
|
Time Accuracy
|
20ns
|
|
Tilt surveying
|
<±2.5cm, within 60° tilt
|
|
DATA FORMAT
|
|
Data output format
|
- NMEA-0183
- RINEX 3.02/3.04
- Binary format *.xyz
|
|
Data update rate
|
1~50Hz selectable
|
|
Correction data format
|
- RTCM v3.3/3.2/3.1/3.0
- CMR
|
|
Supported protocols
|
Ntrip client, Ntrip Server, Ntrip Caster, TCP
|
|
COMMUNICATION
|
|
UHF modem1
|
- Working range: : Up to 15km with
optimal conditions
- Frequency range: 410-470MHz
- Protocol(TX/RX): CSS,TRIMATLK, TRANSEOT,
SATEL, TRIMMARK3, etc.
- Channel spacing: 25KHz
- Transmit power: 0.5W~2W selectable
|
|
Bluetooth
|
BT4.0 dual mode
|
|
NFC
|
Support NFC connection
|
|
Interface
|
- 1 7-pin lemo port for RS232
transmission and power supply
- 1 TNC connector for UHF antenna
- 1 Type-C USB port for static data
download & firmware upgrade
|
